Precision Weight Indicator Model EL43

Precision Weight Indicator Model EL43






View Specifications

Download User Manual

Buy Precision Weight Indicator NOW


Application: Reliable 7 Digit programmable indicator with RS232 output and auto-calibration

Platform Scales, mechanical to electronic scale conversions, crane scale, forklift scale, remote scales, weigh bridges.

  • Highest Precision

  • SMT Technology for high reliability

  • Fully computerized with parameter set-up

  • Built-in Power Supply

  • All required connectors supplied

  • Mounting bracket supplied

  • Professional Quality

  • Kg/ Lb switchable

  • Low Cost


Main Specifications

* Displays the gross weight/net weight/tare weight
* Kg/Lb conversion
* Counting Mode
* Peak Hold
* RS232
* 8 data bits with no parity bit and one stop bit
* Serial Port for printing

Technical Specifications

Internal Resolution : 500,000 : 1
Display Resolution : 30,000 : 1
Input Sensitivity : 0.4 V / d
A/D Conversion Rate : 50 times / sec
Display : 7-digit LED Display
Display Size : 0.54" (13.7mm) display height
Status Indicators : 7 LED
Keyboard Functions :  Lb/kg  -  Zero  -  Net/Gross -- TARE -- Print
Non-Linearity : 0.01% F.S.
Max. Input Signal : 15 mV
RS232 Interface : programmable baud rate
Load Cell Exitation : 5 Volt DC 80mA for 4 x 350 Ohm load cell
Operating Temperature : 0C to 40C
Maximum Humidity : 90%RH @ 40 C
Dimensions : 81mm (H) x 173mm (W) x 57mm (D)
Power Supply : 220V, 110V AC or 6Volt DC
